Overview

The disposable glass line was built in 2021 and has less than 1000 operating hours. The machine is currently set up for 150ml jars, but can be converted to 500ml.

Technical data

CONTAINER

• Container name: 150 g jar
• Container type: Yoghurt jar
• Volume [ml]: 150
• Diameter [mm]: 60
• Height [mm]: 85

PALETTE

• Container: 150g
• Pallet type: EURO pallet
• Pallet material: Wood
• Pallet dimensions (LxWxH): 1200 x 800 x 145 mm
• Transport direction: Lengthwise
• Number of layers: 18
• Number of containers / layer: 27
• Formation: 4x2x1 tray with cardboard lid (pack of 8)

Machines

• Automatic depalletizer - KHS Innopal - AS 1N Year of construction 2005
• Conveyor technology empty packs and empties inspection -Heuft
• Filling machine VMS KONTIFILL GLASSLINE 16/UC 10.000bph, ultra clean H2O2, 2 colored 3x A / 3x B, underlaid or stirred yoghurt
• Closure inspection - Heuft final view
• Full product X-ray - Heuft Examiner XAC2
• Bottle buffer - Krones Acculoop
• Labeler: self-adhesive label for closure with tamper-evident seal -> 2 colors / belly label - cold glue unit -> 2 colors
• Domino laser coding system
• Krones Checkmat for label inspection and best-before date printing, line distributor 1/2
• Somic packer - 2-piece final packaging,
• Automatic palletizer - KHS PB BSN year 2005
