Overview

This steam generator was manufactured in 2012 by the Spanish company ATTSU Termica S.A.. The model RL 2000/8 is a propane gas-fired unit with a production capacity of 2,000 kg/h of steam, designed for industrial applications requiring consistent and efficient heat output. Equipped with a Riello RS190/M T0 burner, the boiler ensures low-emission combustion and high operational reliability. The machine is still installed, in good working condition, and available for inspection.

Technical data

• Fuel Type: Propane gas
• Thermal Power: 1,304,000 kcal/h
• Steam Capacity: 2,000 kg/h
• Operating Pressure (max): 8.9 bar
• Test Pressure: 13.4 bar
• Total Volume: 1,677 L
• Stack Height: 8 m
• Stack Diameter: 0.3 m
• Flue Gas Temperature: 179.5 °C
• CO Concentration: 2 ppm
• NOx Concentration: 82 ppm
• O₂ Content: 6.1 %
• CO₂ Content: 10.7 %
• Burner: Riello RS190/M T0
• Condition: Installed, functional
• Inspection: Possible on-site
