Overview

This KM 790/5K crate decapper was manufactured by Rink in 2002. The machine can be inspected at any time and is immediately available.

Technical details

• Output: approx. 2,800 crates/h (6K), approx. 2,040 crates/h (4K)
• Format parts:
  • 5x centering plates for 0.7l GDB
  • 5x centering plates for 0.75 Gastro
  • 3x centering plates for 0.5l GDB/0.5l Euro
• Crate conveyor speed: 0.6 m/s
• Crate guide: All crates are moved lengthwise through the machine
• Noise level: 83 dB(A)
• Space requirement (LxW): 4,100 x 1,260 mm
• Working area: min. 1,500 mm on the operating side
• Hydraulics: Working pressure 150 bar, residual pressure 35 bar
• Pneumatics: Air consumption approx. 5.2 m³/h at 5 bar; operating pressure min. 5 bar, max. 10 bar; connection size ½"
• Electrical: Operating voltage 230/400 V; control voltage 24 V; power 12.0 kVA; frequency 50 Hz; fuse protection 3 x 25 A min.; supply line min. 2.5
• Control: PLC control Siemens S7-300, HMI Simatic OP7
