Overview

This tray former and case sealer packaging module was manufactured in 2016 by Denmark SOCO SYSTEM A/S.
The system consists of an automatic tray former and a case sealer designed for fully automated carton handling in packaging lines. The tray former erects flat carton blanks into trays, which are transferred via conveyor to downstream processes, while the case sealer applies self-adhesive tape to close cartons after filling.

Technical data

• Capacity: 12 – 14 cycles/min (tray former)

• Application: Carton forming and sealing

• Configuration: Automatic tray former with pneumatic forming system and automatic case sealer with tape sealing

• Utilities:

  • Voltage: 3 × 400 V

  • Frequency: 50 / 60 Hz (tray former), 50 Hz (case sealer)

  • Air consumption: approx. 31.3 Nl/cycle (tray former), approx. 0.6 Nl/cycle (case sealer)

  • Air pressure: 0.6 – 1.0 MPa

  • Rated current: 2 A (tray former), 3 A (case sealer)

Scope of Delivery

• Tray former | SOCO SYSTEM A/S | BE 2200 ATS R | 2016 | Automatic tray former with pneumatic forming system and HMI control
• Case sealer | SOCO SYSTEM A/S | T-402 | 2016 | Automatic tape case sealer with conveyor integration
