Overview

This packaging line for repacking glass bottles into carriers, trays, cartons and dollies was produced between 2002 and 2016 by several European manufacturers such as Yaskawa, Profipack, DokuConsult KG and Krones. The line is currently still in operation until June 2025 and was specially designed for repacking 0.33L and 0.5L glass bottles into 6-bottle carriers (open baskets), returnable trays and various pallet types (Euro dolly, Euro pallet). It enables both the unloading and loading of full and empty containers into new packaging units. The system will be available from June 2025, as soon as it is decommissioned.

Technical details

• Output: up to 9,000 bottles per hour
• Formats processed:
  • 0.5L NRW returnable bottles (brown)
  • 0.33L non-returnable bottles (green and brown)
  • 6 open basket carriers (2x3) for 0.5L and 0.33L
  • Euro dolly: 400 x 600 x 1,600 mm
  • Euro pallet: 1,200 x 800 x 144 mm
  • Basic crate 20x 0.33L: 300 x 400 x 290 mm
  • Modular crate 20x 0.5L: 300 x 400 x 290 mm
  • Logipack AllCare tray: 400 x 600 x 85 mm
  • "Rollfix" adapter pallet: 1,200 x 800 x 126 mm
  • Full carton with flash bottom (single or double-wall) for 4x 6-pack carriers
• Repacking configurations:
  • From modular box 20x 0.5L → 6-pack carrier in tray on Euro dolly
  • From modular crate 20x 0.5L → 6-carrier in tray on Euro pallet
  • From basic crate 20x 0.33L → 6-carrier in carton
  • Returnable crate 24 x 0.33 → 6-carrier in pinol crate 4 x 6-carrier
  • Empties 0.5L in tray (Euro dolly or pallet) → Modular crate 20x 0.5L

Scope of delivery

• Unloading robot cell: Yaskawa / Profipack, MOTOMAN MH 180 II (2016) incl. head & crate handling
• Loading robot cell: Yaskawa / Profipack, MOTOMAN MH 180 II (2016)
• Bottle carrier erector: DokuConsult KG, FTA-6/4-Z1-G5 (2016)
• Double turning station: Profipack (2016)
• Pallet magazine: Krones, type 454 model LPMH (2002)
• Deck tray feeder
• Vertical strapping machine for dollies | Strapex
• Horizontal strapping machine for dollies | Strapex
• Pallet merging

Spare parts can be purchased in addition to the purchase price
