Overview

This fully automatic KEG cleaning and filling system from ATS Wibbing GmbH, built in 2025, is consisting of an external KEG washer (AW 75), a KEG cleaning and filling machine (HRF 101), as well as a complete supply and transport system. The system is designed for the processing of a wide range of KEG formats. With an output of approx. 30–35 KEG/h, the installation is suitable for small and medium-sized breweries or beverage producers. The line is equipped with a Siemens S7-1500 control system and touchscreen HMI, allowing fully automatic operation with guided user interface. The scope includes a complete transport system, supply tanks with dosing and conductivity measurement, as well as all required piping between the machine and media tanks.

The system is offered with 2 years manufacturer warranty and is available within approximately 2-3 months. The attached project layout drawing illustrates the complete system arrangement including KEG washer, cleaning/filling machine, conveyor sections, pallet handling aid, supply station, and expansion vessel.

Technical Data

• Manufacturer: ATS Wibbing GmbH

• Machine Type: Fully automatic KEG cleaning and filling line

• Main Components: ATS external washer AW 75, ATS cleaning and filling machine HRF 101, Supply and transport system

• Year of Manufacture: 2025

• Availability: approx. 2-3 months

• Capacity: approx. 30 – 35 KEG/h

• Suitable KEG Formats: Stainless steel KEGs, Plus-KEGs, Party-KEGs, Containers, Diameter range: 160 – 420 mm, Height range: 280 – 600 mm

• Control System: Siemens S7-1500

• HMI: Touchpanel with operator guidance

• External Washer AW 75: Indexed pass-through operation, Circulation bath approx. 270 l, Spray pump 2.2 kW, Bag filter with pressure monitoring

• Cleaning & Filling Machine HRF 101: Stainless steel control cabinet, Fully automatic cleaning and filling process

• Transport System: Roller conveyor and chain conveyor sections, Complete electrical and sensor equipment, Cable trays included

• Supply System: 4 stacked tanks (150 l each, 120 l usable volume), 3 tanks with heating, Stainless steel pumps, Temperature control and dry-run protection, Temperature and level indication, 2 conductivity measurement systems with dosing pumps, Complete piping between machine and tanks, Pressure and temperature monitoring for product, CO2, sterile air, and steam, Separate control cabinet

• Expansion vessel 150 l

• Pallet handling aid

• Required Utilities: Sterile air: approx. 3 bar, Working air: approx. 6 bar, CO2: approx. 2–3 bar, Steam: max. 3 bar, Water supply: min. 50°C

• Warranty: 2 years manufacturer warranty
