Overview

This Innopro KZE 21/T14-98-12 PT100 A flash pasteurizer was built in 2018 by the German manufacturer KHS. It was never put into operation as there was insufficient process energy available on site. The cooling technology was also not connected due to the lack of a cooling circuit. A functional and pressure test was successfully carried out in March 2025, including a manual pressure test up to 15 bar and a complete valve test.

The system has been dismantled and is ready for transportation. An on-site inspection is possible by arrangement.

Technical details

• Capacity (nominal): 21 m³/h
• Min. capacity: 7.5 m³/h
• CIP capacity: 25 m³/h
• Hot water capacity: 22 m³/h
• Max. CO₂ content in the product: 7.7 g/l
• Product temperature inlet: 20 °C
• Pasteurization temperature: 98 °C
• Holding time: 30 s
• Cooling medium inlet temperature: 28.7 °C
• Hot water inlet temperature: 118 °C
• Product temperature outlet: 12 °C
• Cleaning: possible via external CIP system (not included in the scope of delivery)
