Overview

This fully automatic linear self-adhesive labelling machine was manufactured in 2019 by the German company b+b Automations- und Steuerungstechnik GmbH. The b+b RAPID SM system is designed for precise and reliable labelling of formed glass containers using pressure-sensitive (self-adhesive) labels.

The machine is suitable for the application of seal labels, side labels and back labels on small to medium-sized glass containers and is designed for continuous industrial operation. Thanks to its modular design, pneumatic product handling and modern Siemens S7 PLC control, the system offers high flexibility and stable performance.

The machine is in good condition, has been regularly maintained, and is fully functional.

Technical Data

• Capacity: Up to 40 pcs/min (depending on container size)
• Formats: Formed glass containers (approx. 0.05 l – 0.7 l)
• Labelling Type: Self-adhesive (pressure-sensitive)
• Label Positions: Seal label, side/front label, back label
• Label Applicators:
  • RAPID 60 SM (max. label width 60 mm)
  • 2x RAPID 120 SM (max. label width 124 mm)
• Label Formats:
  • Side label: max. 85 mm (W) × 70 mm (L)
  • Seal label: max. 20 mm (W) × 150 mm (L)
• Label Roll Specifications:
  • Core diameter: 76 mm
  • Outer diameter: max. 290 mm
  • Winding: outside winding
• Dimensions: Approx. 2,510 × 1,400 × 1,800 mm (L × W × H)
• Weight: Approx. 450 kg
• Working Height: Adjustable, approx. 800 – 900 mm
• Power Supply: 400 V / 3 Ph / 5.5 kW
• Pneumatic Supply: 1/2", 6 bar, clean and oil-free compressed air
• Direction of Operation: From left to right
• Control System: Siemens S7 PLC

Scope of Delivery

• Fully automatic linear labelling machine b+b RAPID SM
• Conveyor system with adjustable speed
• Pneumatic product separation and alignment stations
• Upper stabilization belt
• Product rotation station
• RAPID 60 SM and 2x RAPID 120 SM label applicators
• Domino V120i thermal transfer printer
• Product sensor set
• Electrical control cabinet with Siemens S7 PLC
