Overview

This crate washer was manufactured by the German company Klotzki in 2011. It is designed for cleaning beverage crates and has been regularly serviced. The machine is immediately available and was last used in a beverage production plant. It shows regular signs of use, but is still in working condition. The operator platform is not included in the scope of delivery.

Technical data

• Capacity: 1,500 – 2,500 crates/h (adjustable)
• Treatment time per crate: ~91 sec at 1,700 crates/h, ~65 sec at 2,400 crates/h
• Crates in machine: 48 pieces
• Crate format: customizable
• Running direction: transverse
• Spray pressure: approx. 4.0 bar
• Lye tank volume: approx. 1.0 m³
• Treatment section length: approx. 34 meters
• Main pump: 15 kW, 80 m³/h
• Drive units:
  • Main drive: 0.33 kW
  • Crate infeed: 0.55 kW
  • Crate outfeed: 0.55 kW
• Dimensions:
  • Length: 3,000 mm
  • Width: 2,000 mm
  • Height: approx. 5,000 mm
  • Crate infeed height: 1,100 mm
  • Crate outfeed height: 4,100 mm
• Weight: approx. 1,500 kg
• Water connections:
  • Cleaning water inlet: R 1 1/4”
  • Rinsing connection: R 3/4”
• Construction: stainless steel (except drives)
• Control system: LOGO controller
• Electrical installation: per customer specification

Scope of Delivery

• Spiral crate washer (upper unit)
• Lower tank body
