Overview

This complete Bag‑in‑Box filling line was manufactured by OETTEL Maschinen GmbH, CERMEX, and PRECIA MOLEN.

The line is designed for filling water and syrup into Bag‑in‑Box formats. It was in service until September 2025 and is currently stopped, still installed, with energy disconnected. The line is described as fully operational, is available immediately, and can be visited on request. Preventive maintenance was carried out twice per year; the last maintenance took place in January 2025.

Palletizing, stretch wrapping, and pallet labelling equipment were upgraded in 2017 and 2023.

Technical data

• Capacity:
  • 5 L BIB: 650 BIB/hour / 7 pallets/hour
  • 19 L BIB: 420 BIB/hour / 13 pallets/hour
• Formats: 5 L / 19 L Bag‑in‑Box
• Application: Water and syrup
• Configuration: Carton forming, Bag‑in‑Box filling, checkweighing, carton closing, conveying, palletizing, stretch wrapping, pallet labelling

Scope of Delivery

• Carton erector | CERMEX | F37 | 1999 | Formeuse de carton
• Bag‑in‑Box filler | OETTEL | A 4001 | 1999 | BIB filling machine
• Checkweigher | PRECIA MOLEN | X241‑DCKW | 1999 | Weight control
• Carton closer | CERMEX | C642.41 | 1999 | Carton closing
• Carton conveyors | ANDUZE |- | 1998 | Conveyor system
• Labeller | VIDEOJET | APL 210 LH | - | Carton labelling
• Palletizing robot | BEMA | - | 2017 | Fanuc robotic palletizing system
• Stretch wrapper | BEMA | Silkworm LS | 2017 | Stretch wrapping unit
• Pallet labeller | LOGOPAK | - | 2023 | Pallet labelling machine
