Overview

The rotary filling and capping machine manufactured by Bertolaso in 2022 is currently used for vinegar production. It features 30 filling valves and 4 capping stations and operates based on the vacuum filling principle. The machine can be used with a wide range of shape-stable containers and is suitable for filling low-viscosity, non-carbonated liquids.

Technical details:

Filler: 30 valves (Ø16 mm), model Olimpia 30/1050
Capper: 4 Pick & Place heads, model Sigma P&P 4/350

Bottles: 600 ml & 1000 ml cylindrical (range Ø55–95 mm, H160–360 mm)
Caps: Pre-threaded plastic

Output: 8,000 bph (600 ml) / 6,000 bph (1000 ml)

Material: All product-contact parts in AISI 316 stainless steel
Bowl: Electrically height-adjustable, mechanical float level control

Features:

• Automatic valve opening/closing
• Centralized fill-level adjustment (±50 mm)
• Maintenance-free lifting cylinders
• Automated lubrication system
• Integrated washing/CIP system
• Remote teleservice via Ethernet

Safety: CE compliant, transparent guards with microswitches
Includes: Format parts for 600 & 1000 ml bottles; adjustable star wheels (+/- Ø55-95mm)
