Spadoni 12hL (1,200 L) Fermentation and storage cellar (2019)

Overview

This isobaric maturation tank was manufactured in 2019 by Spadoni. It is designed for the isobaric and isothermal maturation of beverages under pressure, with a working capacity of 1,200L (12 hL) and a total volume of 1,300L (13 hL). The tank is certified up to 3 bar (PED) and equipped with high-quality fittings and insulation. Further information on request.

Technical data

• Capacity:
  • Working: 1,200 L / 12 hL
  • Total volume: 1,300 L / 13 hL
• Pressure:
  • Working pressure: 2 bar
  • Shell: 0.49 bar
  • Factory hydraulic test: 2 bar
  • Certified (PED): 3 bar
• Material: AISI 304 stainless steel
• Insulation: 80 mm polyurethane foam on cylinder and bottom head, stainless steel covered
• Finish:
  • Interior: 2B with polished welds
  • Exterior: brushed grain 120 with polished welds
• Heads: Klopper type (top and bottom)
• Cooling: Cooling jacket on the cylinder
• Manway: Isobaric Ø400 mm, pressure-resistant up to 4 bar
• Connections & fittings:
  • 2 lifting lugs
  • Ladder support
  • CIP tube with top spray ball and 2x butterfly valves NW40
  • Drain valve NW40 with cap and chain
  • Bottom discharge valve NW40 with cap and chain
  • Sight glass level tube (rigid acrylic, graduated in liters)
  • Probe port (PT-100 sensor)
  • Sampling valve
  • Safety valve (calibrated at 3 bar)
• Mounting: Adjustable feet
