KHS Innopro KZE 72/T4-72-12/PT45A Flash Pasteurizer (2013)

Overview

This KHS Innopro KZE 72 is a flash pasteurizer (short-time heating system) for beer, cider and other carbonated beverages, built in 2013 by KHS GmbH (Dortmund, Germany). Working with a plate heat exchanger, it gently pasteurizes at a nominal capacity of 72 hl/h and is designed for a product flow between 24 and 72 hl/h with a maximum CO₂ content of 6.5 g/l. The system comes complete with its 50.8 hl buffer tank and the control cabinet with touchscreen HMI.

The unit comes out of a large brewery, is still installed and can be visited on request.

Technical data

• Manufacturer: KHS GmbH (Dortmund, Germany)
• Model: Innopro KZE 72/T4-72-12/PT45A
• Year of manufacture: 2013
• Machine type: flash pasteurizer with plate heat exchanger
• Nominal capacity: 72 hl/h
• Minimum adjustable capacity: 24 hl/h
• Capacity during CIP cleaning: 85 hl/h
• Maximum CO₂ content in the product: 6.5 g/l
• Pasteurization temperature: 72 °C (beer) / 85 °C (cider)
• Holding time: 30 s
• Product inlet temperature: 4 °C; product outlet temperature: max. 4 °C
• Supply pressures: product 3.5 bar(g), steam 3 - 6 bar(g), coolant 1.5 - 2 bar(g), CIP 4 bar(g)
• Electrical connection: 400 V, 50 Hz, 3-phase
• Dimensions pasteurizer skid: approx. 4,600 x 3,500 x H 2,900 mm
• Weight pasteurizer skid: approx. 3,100 kg (frame incl. plate heat exchanger)

Equipment

• Pasteurizer skid with plate heat exchanger type PT45A, pumps and valve manifold
• Buffer tank: 50.8 hl gross / 45.5 hl working volume, inner Ø 1,600 mm, H 3,420 mm, approx. 1,120 kg, operating pressure up to 5 bar(g), CO₂ and sterile air connections 6 - 8 bar(g)
• Control cabinet with touchscreen HMI
• OEM technical documentation (operating manual)

Condition

Used - good working condition. The system was in production in a large brewery until recently, is still installed and can be inspected.

Availability

Immediately. Location: Netherlands. Dismantling and loading by arrangement.
