Krones VarioFlash B Flash Pasteurizer (2019)

Overview

This Krones VarioFlash B is a flash pasteurization system for beer and beer mix beverages, built in 2019 by Krones AG at its Steinecker plant in Freising, Germany. It pasteurizes 20 - 45 hl/h in a three-stage plate heat exchanger with energy recovery, a heat retention tube and a cooling stage. Everything is mounted on a stainless steel skid with a horizontal 2,100 l buffer tank, and a freestanding stainless steel control cabinet with touchscreen HMI completes the system.

Technical data

• Manufacturer: Krones AG (Werk Steinecker, Freising, Germany)
• Model: VarioFlash B with cooling stage
• Year of manufacture: 2019
• Machine type: flash pasteurizer with plate heat exchanger
• Products: beer, beer mix beverages
• Capacity: 20 - 45 hl/h
• Pasteurization temperature: 71 - 85 °C
• Holding time: 30 s at 45 hl/h
• Max. CO₂ content: 6.5 g/l
• Product inlet temperature: 5 - 15 °C; product outlet temperature: 16 °C
• Energy recovery: approx. 91 %
• Heating requirement at 85 °C: approx. 51 kW (approx. 90 kg/h steam at 6 bar(g), 165 °C)
• Cooling requirement with water circulation at 5 °C: approx. 38 kW (5 m³/h glycol water, 2 - 10 °C)
• Process water: inlet pressure 4.0 bar(g), inlet temperature 6 - 15 °C
• Buffer tank: 2,100 l, max. allowable pressure -1.0 / +7.0 bar, allowable temperature -4 to +98 °C, CE marked

Equipment

• Plate heat exchanger with 3 stages: energy recovery, pasteurization with temperature control, cooling with temperature control
• Heat retention tube with fixed length; PU control depending on temperature and flow rate
• Hot water circuit with separate brazed plate heat exchanger, temperature control, circulation pump and expansion vessel
• Sanitary product pumps: frequency-controlled product feed pump, booster pump for a positive pressure difference towards the unpasteurized product, frequency-controlled product pump to the filler
• Horizontal stainless steel buffer tank, pneumatic valves, inline instrumentation and sanitary pipework on a tubular stainless steel frame
• Freestanding stainless steel control cabinet with touchscreen HMI and main switch

Condition

Used. The system has been removed from production and is stored indoors. It can be inspected by appointment.

Availability

Immediately. Location: Germany.
